4N55TXV Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 16-DIP (0.300, 7.62mm)
- Description: OPTOISO 1.5KV TRANS W/BASE 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
4N55TXV Specifications:
- MfrPart.: 4N55TXV
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOISO 1.5KV TRANS W/BASE 16DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 2
- Voltage-Isolation: 1500VDC
- CurrentTransferRatio(Min): 9% @ 16mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 400ns, 1µs
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 18V
- Current-Output/Channel: 8mA
- Voltage-Forward(Vf)(Typ): 1.55V
- Current-DCForward(If)(Max): 20 mA
- VceSaturation(Max): -
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- 4N55TXV AVAGO (Broadcom), OPTOISO 1.5KV TRANS W/BASE 16DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
4N55TXV, AVAGO authentic parts in stock from AVAGO (Broadcom) authorized distributors, order today, can ship immediately.
