8302401EA Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 16-DIP (0.300, 7.62mm)
- Description: OPTOISO 1.5KV 4CH DARLNG 16-DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
8302401EA Specifications:
- MfrPart.: 8302401EA
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOISO 1.5KV 4CH DARLNG 16-DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 4
- Voltage-Isolation: 1500VDC
- CurrentTransferRatio(Min): 200% @ 5mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 2µs, 8µs
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Darlington
- Voltage-Output(Max): 20V
- Current-Output/Channel: 40mA
- Voltage-Forward(Vf)(Typ): 1.4V
- Current-DCForward(If)(Max): 10 mA
- VceSaturation(Max): 110mV
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- 8302401EA AVAGO (Broadcom), OPTOISO 1.5KV 4CH DARLNG 16-DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
8302401EA, AVAGO authentic parts in stock from AVAGO (Broadcom) authorized distributors, order today, can ship immediately.
