ACPL-312T-000E Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: OPTOISO 3.75KV 1CH GATE DVR 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ACPL-312T-000E Specifications:
- MfrPart.: ACPL-312T-000E
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOISO 3.75KV 1CH GATE DVR 8DIP
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: Automotive, AEC-Q100, R²Coupler™
- PartStatus: Active
- Technology: Optical Coupling
- NumberofChannels: 1
- Voltage-Isolation: 3750Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- PropagationDelaytpLH/tpHL(Max): 500ns, 500ns
- PulseWidthDistortion(Max): 300ns
- Rise/FallTime(Typ): 100ns, 100ns
- Current-OutputHighLow: 2A, 2A
- Current-PeakOutput: 2.5A
- Voltage-Forward(Vf)(Typ): 1.5V
- Current-DCForward(If)(Max): 25 mA
- Voltage-OutputSupply: 15V ~ 30V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- ACPL-312T-000E AVAGO (Broadcom), OPTOISO 3.75KV 1CH GATE DVR 8DIP, Isolators~Isolators - Gate Drivers
